DESCRIPTION

Highlights:

• Selectable On/Off LED nightlight with press and hold dimming function
• Green LED indicates load status, provides locator light in dark and blinks to indicate motion detection
• Selectable time delay of 5 seconds (test), 5 minutes, 15 minutes and 30 minutes for lights to remain on after room is vacated
• Selectable ambient light override when there is acceptable natural light
• Uniform color matched pir lens to device housing
• Bypass feature to allows the sensor to perform as a traditional switch (manual on/manual off)
• Mid size decorator wallplate included with product
• Push pad design provides minimal travel and crisp actuation
• Replaces a standard light or fan switch
• Walk-in-delay feature allows sensor to turn lights off without time delay when motion is detected briefly in room

Specifications:

• Overall Dimensions: 3" L x 5" W x 2" D
• Material: Polycarbonate
• Finish: Gloss
• Type: 3-Way
• Voltage Rating: 120 VAC
• Wattage: 1000
• Frequency Rating: 60 Hz
• Sensing Angle: 180 Deg
• Timer Range: 5 - 30 Min
• Sensor Type: Passive Infrared
• Indicator: Green LED
• Connection: Wire Leads
• Mounting Type: WAll/Box
• Temperature Rating: 0 - 40 Deg C
• Standards: CULus Listed, NOM 426
• Special Features: 1-Pole, 1/2 Hp Motor
• Lamp Type: Incandescent, Magnetic Low-Voltage, Electronic Low-Voltage, Fluorescent, CFL, LED
